INVERTER IGBT MMA WELDING MACHINE

Name: INVERTER IGBT MMA WELDING MACHINE
Rating: 5.0 (59 reviews)

FEATURES:
1.Inverter IGBT technique makes the welder more strong, with compact size but much high duty cycle.
2.Inverter technique makes the welder run in high utilization rate of power.
3.Low open circuit and has good welding quality.
4.Suitable for MMA welding of low carbon steel and low alloy steel with all kinds of welding rods.

Quantity:
Availability:





Inquire

Product Description

ACCESSORIES:

MODEL / ITEM	MINI-100I	MINI-120I	MINI-140I
Input Voltage(V)	1PH220V	1PH220V	1PH220V
Frequencu(Hz)	50/60	50/60	50/60
Rated Input Capacity(KVA)	3.0	3.8	4.5
Power Factor	Cosφ0.93	Cosφ0.93	Cosφ0.93
Max NO-load Voltage(V)	65	65	65
Current Range(A)	20-100	20-120	20-140
Rated Duty Cycle(%)	40	60	40
Usable Electrode(mm)	1.6-2.5	1.6-3.2	1.6-4.0
Insulation Class	H	H	H
Proterction Degree	IP21S	IP21S	IP21S
Dimension(mm)	235x95x130	235x95x130	23595130
Weight(kg)	3.3	3.3	3.3

MMA Welding Machine MINI-100I
